Operating Weight
Rated Bucket Capacity
Operating Weight
Rated Bucket Capacity
69 000kg
4.4m³
Model
Type
Power
Bore & Stroke
Weichai WP15H
6-Cylinder, direct injection, Diesel
566kW/1900rpm
140x166mm
Main pump type
Main Valve
Swing Motor
Boom Cylinder
Bore
Stroke
Stick Cylinders
Bore
Stroke
Bucket Cylinder
Bore
Stroke
Travel Circuit
Implement Circuit
Swing Circuit
Pilot Circuit
Hydraulic Piping
Pump Flow
Pump Pressure
Linde
Linde
Linde
Wuxi Hengli
190mm
1725mm
Wuxi Hengli
200mm
2080mm
Wuxi Hengli
190mm
1470mm
34.3 MPa
34.3 MPa
31.5 MPa
3.9 MPa
Standard
1020L/min
37.3 MPa
Frame
Rail Distance
Track Width of Shoe
Undercarriage Width
Track Length
Number of Carrier Rollers
Number of Track Rollers
X-Type
2830mm
600mm
2890mm/3410mm
5710mm
3
9
Travel Motor
Maximum Travel Speed
KYB MAG-1 S0VP
4.5km/h
Drive Method
Swing Speed
Hydrostatic
6.8 rpm
Boom Length
Stick Length
Bucket Type
Bucket Capacity
6800mm
2800mm
General Purpose/Rock Bucket
3.2m³- 5.1m³
Fuel Tank
Cooling System
Engine Oil
Swing Motor
Final Drive
Hydraulic Tank
800L
60L
52L
10.5L x 2
15L x 2
600L
